DIY Guitar Kit - ES Bigsby (Mahogany, Chrome)
Build Easily Your Own Unique Guitar: Customize your DIY Guitar Kit - ES Bigsby (Mahogany, Chrome). Paint, assemble, and adjust your semi-hollow guitar. Perfect for blues, rock, and jazz. Suited for skilled builders, this kit's uniqueness comes from solderless electronics and comprehensive support.
Premium Quality & Materials: Crafted with mahogany wood for the body and neck, paired with an ebony fretboard and bone nut, our kit promises a quality instrument at a fraction of the usual cost.
Support & Community: Customers love our quality. Check our customer build showcase, downloadable user guides. Benefit from expert support, a patient community, and a flexible return policy. Great for musicians and hobbyists as a personal project or as a thoughtful gift.
*Free & Next Day Delivery in the UK and France | 3-5 Working Days Delivery to Europe | 7 Working Days Delivery to the US | Worldwide Delivery Available
Experience the classic charm of a legendary semi-hollow guitar with our customizable DIY kit. Perfect for builders seeking a hands-on project with classic blues, jazz, or rock tones.
Guitar Build Levels and Challenges
The ES Bigsby Kit is a thrilling project suited for expert builders looking for a rewarding challenge. While painting is relatively approachable thanks to the smooth mahogany body, careful attention is needed around the binding and neck sealing. Assembling demands precision, especially for the set-in neck with inclination — a step that leaves no room for errors once glued. Sound adjustment remains manageable, though the initial neck setup is key to achieving a great string action. If you're ready to take your skills to the next level, this stunning semi-hollow body is just waiting for your craftsmanship!
Key Features
- Mahogany semi-hollow body with double white binding for a classic look.
- High-quality mahogany neck paired with an ebony fretboard, featuring 22 frets and white dot inlays.
- Chrome hardware including Bigsby Tremolo, two humbucker pickups, and a 3-way toggle switch.
We've got your back. Our step-by-step guide walks you through the full build process.
Discover how others brought their kits to life in the Customer Showcase.
Dive deeper into this guitar’s legacy with our Model Review — featuring its history, style, and legendary players.
Specifications
| General | |
| Scale Length | 628 mm (24.75") |
| Hand Orientation | Right Handed |
| Neck / Body Fit | Set-in Joint |
| String Number | 6 |
| Guitar Body | |
| Wood Type | Mahogany |
| # of Wood Block | Made of 2 to 3 blocks of wood |
| Neck Pocket Dimension (LxWxH) | 88x56x36mm (3.46"x2.20"x1.42") |
| Body Height (H) | 46/70mm (1.81"/2.76") |
| Cavity/Routing | Pick-up, Bridge, Neck, Wiring routing, cover plates and switch |
| Pilot Predrill | No pre-drilled pilot holes except for the neck pocket |
| Paint | No lacquer, No sealer, No finish |
| Guitar Neck | |
| Scale Length | 628 mm (24.75") |
| Number of Strings | 6 |
| Tuner Pre-Drilled Holes | 10 mm |
| Wood Type | Mahogany |
| Fretboard | Ebony |
| Inlay | White dot |
| Nut | Bone nut |
| Fret Number | 22 |
| Fret Size | Jumbo Fret |
| Fret Material | CuproNickel |
| Neck Radius | 305mm (12") |
| Neck Profile | Modern C |
| Truss Rod | Double action, on the head side |
| Paint | No lacquer, No sealer, No finish |
| Guitar Hardware | |
| Color | Chrome set |
| Bridge | Tailpiece Bigsby Vibrato, Chrome |
| Pick-up | 2 Humbucker pickups, Chrome (H-H Configuration) |
| Switch | 3-way toggle switch, Chrome with black tip |
| Machine Head | 3R3L, Chrome |
| Knobs | 2 volume & 2 tones |
| Strap Button | Chrome |
| Covers | Black pickguard |
| Wiring | Solderless Wiring |
*This product is not affiliated with, endorsed by, or in any way connected to Fender Musical Instruments Corporation, Gibson Brands, Inc., PRS Guitars, Rickenbacker International Corporation, Ibanez Guitars (Hoshino Gakki), Music Man (Ernie Ball, Inc.), Epiphone, Squier, LAG Guitars, Gretsch, Schecter Guitar Research, Jackson Guitars, ESP Guitars, or any other registered trademarks of these or other companies.
